UG_6613_ 060 6613_OMU_2+2S_URT_V1_00 Firmware Description Document
Rev. 1.1 15
The CLP2 command performs the phase calibration for channel 2.
The CLP3 command performs the phase calibration for both channel 1 and channel 2.
4.5.2.4 CLT Command
The CLT command is used for the temperature calibration. This command adjusts the Temperature
Nominal at MPU location 0xA6, saves to flash and initiates temperature gain compensation. The CLT
command example is given below:
>CLT
The response is:
TCal OK
>
4.5.2.5 CLW Command
The CLW command is used for the power calibration. This command adjusts the power from CLI, saves
to flash. To calibrate the power for channel 1, enter the CLW command:
>CLW or CLW1
The response is:
WCal1 OK
>
The CLW2 command performs the power calibration for channel 2.
The CLW3 command performs the power calibration for both channel 1 and channel 2.
The following table provides a summary of the atomic calibration commands:
Atomic Calibration Commands
Description: Calibrates individual sections of the IC.
Usage: CLV Calibrates voltage only.
CLI Calibrates current only for given channel.
CLI1 = Calibrates channel 1
CLI2 = Calibrates channel 2
CLI3 = Calibrates channel 1 and 2
CLP Calibrate for phase only for given channel.
CLP1 = Calibrates channel 1
CLP2 = Calibrates channel 2
CLP3 = Calibrates channel 1 and 2
CLT Calibrates temperature only.
CLW Calibrates power only for given channel.
CLW1 = Calibrate channel 1
CLW2 = Calibrate channel 2
CLW3 = Calibrate channel 1 and 2
The commands that follow are mainly for advanced users and are included for reference only.
