UG_6613_ 060 6613_OMU_2+2S_URT_V1_00 Firmware Description Document
Rev. 1.1 27
Output
Location
(hex)
LSB Comment Example
Reserved 6F – Reserved Reserved
Vrms B Min 70 mV Minimum Vrms measured
If the minimum line voltage
measured was 105 V
)70
Returns:
+105.000
Vrms B Max 71 mV Maximum Vrms measured
If the maximum line voltage
measured was 130 V
)71
Returns:
+130.000
Watts B Min 72 mW
Minimum active power measured
(per second)
If the minimum power measured
is 80 Watts
)72?
Returns:
+80.000
Watts B Max 73 mW
Maximum active power measured
(per second)
If the maximum power measured
is 200 Watts
)73?
Returns:
+200.000
Irms B Min 74 mArms Minimum rms current measured.
If the smallest current measured is
1 Amp
)74?
Returns:
+1.000
Irms B Max 75 mArms Maximum rms current measured.
If the largest current measured is
30 Amps
)75?
Returns:
+30.000
VARs B Min 76 mW
Minimum reactive power measured
(per second).
If the largest VARs measured
is 80 VARs
)76?
Returns:
+80.000
VARs B Max 77 mW
Maximum reactive power
measured (per second).
If the largest VARs measured
is 300 VARs
)77?
Returns:
+300.000
VAs B Min 78 mW
Minimum apparent power
measured (per second).
If the smallest VAs measured
is 80 VARs
)78?
Returns:
+80.000
