6613_OMU_2+2S_URT_V1_00 Firmware Description Document UG_6613_060
38 Rev. 1.1
CE
Parameter
Location
(hex)
LSB Default Comment Example
WRATE 0F
Kh =
VMAX A *
IMAX A /
(WRATE *
X)
1.6826E+0
1 WattSec
+4860
Controls the
number of pulses
that are generated
per measured Wh
and VARh
measurements.
]0F=+4860
Kh = 0.32 * Wh / pulse with X = 6/64,
VMAX =600 V
and
IMAX = 52 A
Reserved 10 Reserved
SAG
Threshold
11
VMAX A
*4.2551E-
07 (Vpk)
+168225
The voltage
threshold for SAG
warnings. The
default value is 80
Vpk if VMAX = 600
V.
]11=+313350
80 Vpk SAG Threshold.
QUANTA 12
VMAX A *
IMAX A *
1.8541E-
10 (Watt)
0
Compensation
added to the Watt
calculation. Used
for compensation at
low current levels.
Keep below
10000d.
QUANTB 13
VMAX A *
IMAX B *
1.8541E-
10 (Watt)
0
Compensation
added to the Watt
calculation for
Outlet 2. Used for
compensation at
low current levels.
Keep below
10000d.
QUANT
VAR A
14
VMAX A *
IMAX A *
1.8541E-
10 (Watt)
0
Compensation
added to the VAR
calculation for
Outlet 1. Used for
compensation at
low current levels.
Keep below
10000d.
QUANT
VAR B
15
VMAX A *
IMAX B *
1.8541E-10
(Watt)
0
Compensation
added to the VAR
calculation for
Outlet 2. Used for
compensation at
low current levels.
Keep below
10000d.
