UG_6613_ 040 6613_PSU_1+1S_URT_V1_00 Firmware Description Document
Rev. 1.0 25
MPU
Parameter
Location
(hex)
LSB Default Comment Example
Calibration
Current
C2 mArms +1.000
Target load current (rms) used for
calibration.
If the target load current for
calibration is 2A, enter the
following:
>)C2=+2
Calibration
Phase
C3 0.1° +0
Target Phase (voltage to current).
Normally set to zero.
Tolerance on
Voltage
C4 mVrms +0.010
Measured value to fall within this
set tolerance of the target value
(Calibration Voltage entry) for the
calibration to be complete.
If the tolerance to the target
voltage is desired to be
more coarse, to within
0.1V, the user can enter the
following:
>)C4=+0.100
Tolerance on
Current
C5 mArms +0.010
Measured value to fall within this
set tolerance of the target value
(Calibration Current entry) for the
calibration to be complete.
If the tolerance to the target
current is desired to be
more coarse, to within
0.1A, the user can enter the
following:
>)C5=+0.100
Average
Count for
Voltage
C6 1 +3
Number of voltage measurements
taken and averaged to be
compared to the target value
(Calibration Voltage entry).
If the amount of averaging
for the voltage
measurement is desired to
increase to 10 enter the
following:
>)C6=+10
Average
Count for
Current
C7 1 +3
Number of current measurements
taken and averaged to be
compared to the target value
(Calibration Current entry).
If the amount of averaging
for the current
measurement is desired to
increase to 10 enter the
following:
>)C7=+10
Max Iteration
for Voltage
C8 1 +10
Number of attempts to reach the
target value (Calibration Voltage
entry) within the programmed
tolerance.
If maximum number of
iterations to be tried for
obtaining the target value of
voltage within the set
tolerance (at C4) is to be
reduced to 5, then enter:
>)C8=+5
Max Iteration
for Current
C9 1 +10
Number of attempts to reach the
target value (Calibration Voltage
entry) within the programmed
tolerance.
If maximum number of
iterations to be tried for
obtaining the target value of
power within the set
tolerance (at C5) is to be
reduced to 5, then enter:
>)C9=+5
