UG_6613_ 040 6613_PSU_1+1S_URT_V1_00 Firmware Description Document
Rev. 1.0 21
Output
Location
(hex)
LSB Comment Example
Reserved 2F – Reserved Reserved
Vrms A Min 30 mV Minimum Vrms measured
If the minimum line voltage
measured was 105 V
)30
Returns:
+105.000
Vrms A Max 31 mV Maximum Vrms measured
If the maximum line voltage
measured was 130 V
)31
Returns:
+130.000
Watts A Min 32 mW
Minimum active power measured
(per second)
If the minimum power measured
is 80 Watts
)32?
Returns:
+80.000
Watts A Max 33 mW
Maximum active power measured
(per second)
If the maximum power measured
is 200 Watts
)33?
Returns:
+200.000
Irms A Min 34 mArms Minimum rms current measured.
If the smallest current measured is
1 Amp
)34?
Returns:
+1.000
Irms A Max 35 mArms Maximum rms current measured.
If the largest current measured is
30 Amps
)35?
Returns:
+30.000
VARs A Min 36 mW
Minimum reactive power measured
(per second).
If the largest VARs measured
is 80 VARs
)36?
Returns:
+80.000
VARs A Max 37 mW
Maximum reactive power
measured (per second).
If the largest VARs measured
is 300 VARs
)37?
Returns:
+300.000
VAs A Min 38 mW
Minimum apparent power
measured (per second).
If the smallest VAs measured
is 80 VARs
)38?
Returns:
+80.000
