November 10, 2008 / Version: 2.0 52
Product Specifications
Standard
IEEE 802.11n draft 2.0,
IEEE 802.11g,
IEEE 802.11b,
IEEE 802.3,
IEEE 802.3u
Interface
LAN: 4 port 10/100Mbps Ethernet, RJ-45
WAN: One RJ-45 port
3* wireless antennas
1* Reset to default button
1* WPS button
Antenna
Antenna gain: 2dB
Antenna type: Dipole
Antenna connector type: Reverse SMA
WAN Connection Ethernet 10/100 Mbps
Cable Connections
RJ-45 (10BASE-T): Category 3,4,5 UTP
RJ-45 (100BASE-TX): Category 5 UTP
Transmission Mode Auto-Negotiation (Full-duplex, Half-duplex)
LED indications
1*Status,
1*WAN,
4*LAN,
1*WLAN
Security 64/128-bit WEP, WPA, WPA2
Network Data Rate
802.11b: 1,2,5.5, and 11Mbps
802.11g: 6,9,12,18,24,36,48 and 54Mbps
802.11n: up to 300Mbps
Receiver Sensitivity 802.11b-91dBm, 802.11g-78dBm, 802.11n -69dBm
Transmit Power
802.11b 19dBm, 802.11g 16dBm,
802.11n 20MHz and 802.11n 40MHz 16dBm
Channel USA 11, Europe 13
Range Coverage
Indoor 35~100 meters
Outdoor 100~300 meters.
Emission
FCC CLASS B, CE
FCC Part 15.247 for US (2.412~2.462MHz)
ETS 300 328 for Europe (2.400~2483.5MHz)
DGT LP0002 for Taiwan (2.412~2.462MHz)
Temperature
Operating: 0° ~ 40°C
Storage: –10° ~ 70°C
Humidity
Operating: 10 ~ 90% RH, non-condensing
Storage: 5~95% RH, non-condensing
Power Supply External Power Adapter, 12VDC/ 1A
