WDS (AP Bridge)

AP+WDS (AP Repeater)

Items

Information
Select the option in the drop-down list to enable
AP+WDS (AP Repeater), WDS (AP Bridge) or Auto
(AP Bridge) as WDS mode.

WDS Mode

Select the option in the drop-down list to enable CCK,
OFDM, HTMIX, or GREENFIELD mode for physical
layer transceivers.

Phy Mode

Select the option in the drop-down list to enable WEP,
TKIP, and AES encryption types. If you select None,
any data will be transmitted without encryption and any
station can access the router.

Encryption
Type

For encryption type of TKIP and AES, you have to fill in
the WPA encryption key. Please use Pass Phrase
(8~32bytes) key format.

Encryption Key

For encryption type of TKIP and AES, you have to fill in
the WDS AP MAC. You can fill up to 4 sets of WDS AP
MAC lists.

WDS Partner
1~4 MAC

* Please click on the Save Settings button or the Reset Settings button on the above table

to save/reset the configurations.
