November 10, 2008 / Version: 2.0

HT (Hyper Throughput)

Physical Mode

Items

Information
Select the mixed or green field mode as the
operation mode.

Operating Mode

Select the 40Mhz or 20/40Mhz as the channel
bandwidth.

Channel Bandwidth

Select 400ns or 800ns as the interval time.

Guard Interval

Mark to enable Hyper Throughput TX Aggregate
MAC Service Data Unit, and clear to disable.

Aggregation MSDU

Select to block ACK (Acknowledge Number) or
not during data transferring.

Auto Block ACK

Select to reject peer BA-Request or not

Decline BA Request

* Please click on the Save Settings button or the Reset Settings button on the above table

to save/reset the configurations.

Security Settings

The Security function protects your wireless network from invasion. We provide WEP

and WPA encryption to secure your wireless network. As default, the authentication is

configured as safe mode. Please select None/WEP/WPA (Personal) in the drop list. If

you select none, any data will be transmitted without encryption and any station can

access the router.

Items

Information
Please choose a SSID you have set for this
router in the

from the drop-down list. The SSID will be shown
on the wireless network for recognizing.

SSID choice

Security Mode

There are 6 modes for you to select: Open,
Shared, WEP Auto, WPA-PSK, WPA2-PSK, and
WPA-PSKWPA2-PSK. Please refer to the
following description.
