Air and Auxiliary Features
(When Applicable)
System has the option to control external Air and Auxiliary features.
When enabled, the feature works according to the following logic:
• Air bag pressure automatically lowered when starting the auto or manual sequence to maximize lift
of jacks.
• An Auxiliary mode activated when starting an auto retract sequence to fill air bags.
• Auxiliary is active when jacks are all retracted and park brake is disengaged to fill airbags.
Air and Auxiliary Feature Configuration
For Diesel Units with Airbag Suspensions ONLY:
• Feature is entered ONLY after zero mode programming.
• At this point the Wait LED will blink for 20 seconds. You are now in Air/Auxiliary Feature
Configuration mode.
To enable Air Auxiliary features, perform the following:
1. Press the Retract All switch 3 times.
2. User must do this within 20 seconds of entering this mode.
To disable Air features, perform the following:
1. Do nothing.
2. After 20 seconds, module will exit mode with features disabled.
Miscellaneous
• The system will automatically shut down after 4 minutes of no operation.
• Auto leveling cycle cannot be started until all jacks are fully retracted. Make sure jacks are retracted before
attempting to auto level. (Unit will perform full retract automatically if jacks are not down on the request of
an auto cycle.)
• System will refuse any operation when a low voltage condition is present.
• System will automatically alarm and retract if park brake is disengaged and jacks are not retracted with any
change in sensor readings. In alarm mode, the only available feature is to retract all jacks.
• Please note the Wait LED shows the status of Air/Auxiliary features.
The LEDs blink differently when in special controller modes (error, alarm and configuration). Learning how to
recognize these modes is important. Excess slope LED blinks whenever the Y axis (vehicle length) is over 50
degrees from programmed level point.
