Rev: 03.17.2014 LCI Motorized Leveling (2009 - Present) Owner's Manual
Page 11
Automatic Leveling Procedure
NOTE: Refer to Fig. 3 for questions regarding location and functions of the Lippert Components, Inc.
Electronic Leveling System.
NOTE: Coach must be running and parking brake must be engaged for LCI Electronic Leveling System to
operate.
1. Push ON/OFF button on Control Panel. The system is now operational and the electronic level lights
will become active.
2. Check to see that the Control Pad ENGAGE PARK BRAKE light is not flashing.
3. Push the AUTO button to begin the automatic leveling cycle.
NOTE: After starting the automatic leveling cycle it is very important that you do not move around in the
coach until the unit is level and the green LCI logo light illuminates in the center of the touchpad.
Failure to remain still during the leveling cycle could have an affect on the performance of the
leveling system.
4. If further adjustments are necessary, refer to the Manual Leveling Procedures section below.
Lifting all wheels of the ground may result in serious personal injury or death.
5. Push power button to turn off the system.
Manual Leveling Procedures
NOTE: When leveling your coach, the coach should be leveled from front to rear first (Step 2-4). When the
coach is level from front to rear, then level the coach from left to right (Step 5).
NOTE: Coach must be running for LCI Electronic Leveling System to operate.
1. Push ON/OFF button on control panel. The system is now operational and the ON/OFF light will be lit.
2. Push and hold MAN button for 5 seconds.
3. Push FRONT button until jacks contact the ground and lift the front of the coach 1-2 inches.
4. Push REAR button until jacks contact the ground and lift rear of coach. Keep button depressed until
bubble is centered.
5. Push LEFT or RIGHT button; if bubble is towards left of coach, push RIGHT button; if bubble is towards
right of coach push LEFT button. Keep button depressed until bubble is centered in vial.
NOTE: The right and left jacks are used to level the coach side to side. Pushing the LEFT button on the
control panel will extend both left jacks. Pushing the RIGHT button on the control panel will extend
both right jacks. Jacks always work in pairs, both front jacks; both right side jacks, etc.
6. Repeat steps 2 through 5 if needed.
7. Turn power off to leveling system by pushing ON/OFF button.
8. Visually inspect all jacks to ensure all shoes are touching ground. Should one of the rear jack shoes
not be touching the ground, press the corresponding LEFT or RIGHT rear jack buttons to lower the
corresponding jack to the ground.
Lifting all wheels of the ground may result in serious personal injury or death.
