SB-293 Satellite Board
1530 Old Oakland Road, Suite 100 01837-003 Rev. 2.3
San Jose, CA 95112 USA
(800) 260-5265 (408) 451-2520 FAX (408) 441-0309
Web: http://www.kerisys.com E-mail: [email protected]
Page 12 of 16
Quick Start Guide
SB-293
7.2 General Purpose Input/Output Configuration Connections for Doors
This configuration assumes JP12 is ON configuring the Satellite board for general purpose inputs and outputs.
7.2.1 Output Relays Table
Please refer to Figure 4 on page 4 for output relay wiring locations.
• See page 13 for a sample General Purpose Normally-Closed Relay drawing.
• See page 13 for a sample General Purpose Normally-Open Relay drawing.
Table 4: Output Relays
TB-7/TB-10 Relay Outputs Description
TB-7 – Pin 1 GPO 1 – normally open line
TB-7 – Pin 2 common/ground
TB-7 – Pin 3 GPO 1 – normally closed line
TB-7 – Pin 4 GPO 2 – normally open line
TB-7 – Pin 5 common/ground
TB-7 – Pin 6 GPO 2 – normally closed line
TB-10 – Pin 1 GPO 3 – normally open line
TB-10 – Pin 2 common/ground
TB-10 – Pin 3 GPO 3 – normally closed line
TB-10 – Pin 4 GPO 4 – normally open line
TB-10 – Pin 5 common/ground
TB-10 – Pin 6 GPO 4 – normally closed line
