8
31 LFO waveshape (default :TR)
- Sets the LFO waveshape. All waveshapes modulate CV and/or Aux any value between 0 to
a positive value, except triangle, which modulates positive and negative. The following may
be selected; (the downward arrow (
↓ ) indicates the default trigger point when in MIDI sync
mode). Note that this can be changed using parameter #33
↓ ↓
Triangle [TR] Sawtooth up [SU]
↓ ↓
Sawtooth down [SD] PulseWidth 10% [10]
↓ ↓
PulseWidth 20% [20] PulseWidth 30% [30]
↓ ↓
PulseWidth 40% [40] Square [50]
↓
Sample + Hold [SH] (Pseudo random)
(actually a new S/H level for each trigger)
32
LFO MIDI SYNC (default: off)
Range, off [of], 1 to 96
- Allows the LFO waveform to be synchronised to MIDI clock, with a variable divide ratio. The
LFO waveform will automatically adjust its length so that it will start at the beginning of a bar,
and last for whatever musical time it is set for (see below for divide ratios).
A divide ratio can be set, so the LFO only re-triggers every so many MIDI clock messages;
If set to 1, there will be 1 cycle of the LFO for every 1 MIDI clock. (i.e. 24 cycles per quarter
note). If set to 24, there will be 1 cycle of the LFO for every 24 MIDI clocks. (i.e. 1 cycle of the
LFO per quarter note).
Note; MIDI sends 24 clocks per quarter note.
Below is a table of values you can set the divide ratio to obtain LFO cycles of various musical
lengths:
Note
type; Divide ratio;
Semibreve 96
Minim 48
Crotchets 24
Crotchet triplets 16
Quavers 12
Quaver triplets 8
Semiquavers 6
Semiquaver triplets 4
Demisemiquavers 3
Demisemiquaver triplets 2
33
LFO Sync Start Point (default :0)
Range
0 to 255
- Sets where the waveform will start when MIDI sync is active or Key-On reset is on.
34 Key-On resets LFO Wave (default :0)
The following can be selected:
Off
[oF]
On [on]
- The LFO waveform is reset to the selected start point whenever a new note is played.
