Chapter 3 Avaya P460 Chassis and Module Installation
16 Avaya P460 Installation and Maintenance Guide
I/O Module Installation
L If you purchased an Avaya P460ML-CFG (Material code 700255003, PEC Code
4548-009), then one Supervisor Module, PSU and the Fan Module are already
installed.
Figure 3.10 shows the positions of I/O modules installed in the P460 chassis.
Figure 3.10 Lcoation of Avaya P460 I/O Modules
L You can install I/O modules in the bottom four slots – 3 to 6 – only.
Caution: Do not leave any slots open. Use the the blanking plates supplied to cover
empty slots.
Caution: The I/O modules contain components that are sensitive to static discharge.
Handle the module by the edges only.
Use appropriate anti-static equipment when handling the switch and modules.
