Figure 3.3 shows the two mounting positions:
Figure 3.3
P460 Front-Mount and Mid-Mount Positions (side view)
Key
a
Rack
b
P460 switch
L The chassis height is 10U.
5.5”
(140 mm)
a
b
a
b
Front
Front
Front-Mount
Mid-Mount
