Appendix B: Technical Specifications AXIS 1610 User’s Manual 54
RJ-45 connector (Category 5 Unshielded Twisted Pair) for
10baseT Ethernet and 100baseTX Fast Ethernet
Security
A Root password protects the configuration settings
Parallel Printer
One IEEE 1284 compliant high-speed parallel port, 36-pin
Centronics connector. Sustained throughput of 800 kbytes/s
(100baseTX) and 600 kBytes/s (10baseT). ECP support
Front Panel
2 LED indicators: Power and Network
Test button
Power Consumption
external power supply Maximum 200 mA at 12 VDC. (Type PS-B, 12V, 500 mA)
Dimensions
Height x Width x Depth
0.9 x 2.4 x 4.8 inches (2.4 x 6.1 x 12.1 cm)
Weight
0.22 lb. (0.1 kg)
Environmental
Temperature: 40 - 105° F (5 - 40° C)
Humidity: 10 - 95% non-condensing
Approvals
EMC: EN 55022/1994, EN50082-1/1992. FCC Class A
Safety: EN 60950.
