AXIS 1610 User’s Manual Section 3: Installation 29
Using
AXIS Print Monitor
in Windows NT
and Windows 2000
Follow the procedure below to install NetBIOS/NetBEUI Ports
from a Windows NT 4.0 or Windows 2000 workstation:
1. Install the AXIS Print Monitor on your workstation. The software
is available on the AXIS Product Resources CD.
2. Select Settings | Printers from the Start menu and double-click
the Add Printer icon to start the Add Printer Wizard.
3. Select My Computer, as the AXIS 1610 emulates a local printer
port and click Next>
4. If the port you want to use is in the Available Ports list, you can
proceed to step 8.
If the port does not appear in the list, click
Add Port / Create a
New Port. Select AXIS CAPT Port from the drop-down list and
click
Next>
5. Select NetBIOS/NetBEUI as your choice of network printing
protocol
6. Select the AXIS Port you want to add. The port appears as
, where is AXIS followed by the last six digits of
the AXIS 1610 serial number, e.g. AXIS100086. Click
OK.
7. Close the Printer Ports window and click Next>
8. Select the printer port from the Available Printer Ports list if it is
not already selected. Click Next>.
9. Click the Have Disk... button. Insert the printer driver CD that
was provided with your printer, select the CD drive and click OK.
10. Select the printer driver you want to install and click Next>
11. Enter an appropriate name for your printer and click Next>
12. Choose whether you want to share the printer with other
network users and click Next>
13. Print a test page to confirm the installation and click Finish.
