39
System Confi
guration
When this adjustment is completed, press the ¤ Menu Control button once so that Input
Balance is highlighted. By pressing the ‹ or › Menu Control buttons , you may select Auto ,
or enter a manual offset from a balanced center position (+00dB). Normally, no adjustment should
be needed, but if a source always seems to favor one channel or the other, the imbalance may be
corrected on this line.
If you have selected a digital audio input, the 5.0 will not display either the Input Level or
Input Balance choices, as they are not applicable to digital sources. Instead, the next menu item
after Audio Input will be Auto Detect , with choices of OFF or ON (Figure OSD-9).
Figure OSD-9
When the factory defalut of (Auto Detect ON) is in place, the 5.0 will automatically test an
incoming digital signal to determine which type of decoding should be applied, such as Dolby
Digital, PCM or DTS (when the DTS module is installed).
To “force” a certain method of processing to be tried on an incoming signal, press the ‹ or › Menu
Control button so that the choice moves to OFF . In this position, the 5.0 will always try the
default-selected digital mode first. If that mode is not appropriate to the incoming signal, it will then
change to the correct mode.
Whether the audio input was analog or digital, the next menu choice is the selection of the program’s
video source.
By pressing the ¤ Menu Control button again, Video Input is highlighted. Any of 6 composite
video sources or 2 S-video sources may be selected to associate with the program being customized.
Two other choices are
NONE and OFF . Choosing NONE creates a purely audio program (e.g., CD,
Tape). If NONE is selected, and a video monitor is in use, a blue background will be generated for the
video display. The OFF setting sends NO signal to any connected video display device, preventing those
video projectors whose power is controlled by the presence of an input signal to remain “off ”.
Note: Choosing OFF selects no video input, and also disables the on-screen display; it will be
necessary to use the front panel display until the on-screen is reactivated by selecting any video
source choice but
OFF .
After selecting the video input for the program, the next choice to be made is whether the on-
screen display will be active when this program is selected. Use the
¤ Menu Control button to
highlight the words OSD Display and use either the ‹ or › Menu Control button to select ON
or OFF .
Please note that, as in the selection of a video source in the preceding step, selecting OFF will cause
the on-screen display to blank, and you will have to refer to the front panel display to continue. Or,
if no other menu control buttons have been pressed, simply depress either the
‹ or › Menu Control
button once; the on-screen display will reappear.
P r o g r a m s S e t u p
<
M a i n M e n u <
P r o g r a m 8
N a m e L D d i g i t a
A u d i o I n p u t D 7
( A u t o D e t e c t O N )
V i d e o I n p u t C O M P
1
O S D D i s p l a y O N
T r i g g e r s O n N O N E
