30
System Confi
guration
Figure 5 The distance between the left and right speakers should be equal to the distance from the seating position to the viewing
screen. You may also experiment with placing the left and right speakers slightly forward of the center speaker.
Using these guidelines, you may find that it takes some experimentation to find the correct location
for the front speakers in your particular installation. Don’t be afraid to move things around until the
system sounds correct. Optimize your speaker positions so that pans across the front of the room
sound smooth, and that sounds from all speakers appear to arrive at the listening position at the
same time.
Surround speakers should be placed on the side walls of the room, at or slightly behind the listening
position. The center of the speaker should face into the room. The speakers should be located so that
the bottom of the cabinet is at least two feet higher than the listener’s ears when in the desired area,
as shown below.
Figure 6 Speaker Placement, Side View
At least 2 feet
At least 6 inches from ceiling
Center Front
Speaker
Optional Rear Wall Mounting
TV or Projection Screen
Right Front
Speaker
Left Front
Speaker
No more than 6 feet when rear-mounted speakers are used
