Analog

Digital

Video

Audio

Source Device

Connection

Laser Disc Player

Composite 1

Analog 1

Digital 7
(from RF Demodulator)

VCR

Composite 2

Analog 2

None

Satellite Receiver

Composite 3

Analog 3

Digital 8

Tuner

None

Analog 4

None

CD Player or External D/A

None

Analog 5

Digital 10

CD Changer or External D/A

None

Digital 11

DVD Player

Composite 4

None

Digital 9

3. Connect the

Rec A Audio Output

of the 5.0 to the “Rec/In” input of the audio recorder or VCR

that will be used to record the output of the 5.0. Connect the

Rec A Video Output

to the composite

video input of a VCR that will be used to record the output of the 5.0.

4. Connect the

Main Composite Video Output

on the 5.0 to the Video In jack on your TV monitor

or other video display device. A connection from the

Main S-Video Output

on the 5.0 to the

S-video input on your video display may also be made if you will use S-video sources at a later time.

5. Using high-quality audio interconnect cables, connect the

Audio Outputs

of the 5.0 to the

matching input connection on your amplifier. Note that the 5.0’s preset default is for Citation
or Fosgate • Audionics Dual Drive dipole surround speakers. If you are using standard surround
speakers you will need to make an adjustment at the

Speaker Setup

menu, as detailed on pages

32–33 of this manual.

6. Connect the

Subwoofer Outputs

to the line-level input of powered subwoofers, or to the amp-

lifier that will power passive subwoofers. Note that the 5.0 is shipped for use with stereo subwoofers
as a factory default. If you are using stereo subwoofers, be certain to connect them to the

Sub

Outputs

at the far side of the output jack field. If you are using only one subwoofer, connect it to

the

Mono Sub

jack. If one or no subwoofers are installed, please note that you will have to make an

adjustment to the

Speaker Setup

menu, as described on page 34 of this manual.

7. If a Citation power amplifier, or other compatible power amplifier with 12-volt turn-on trigger
circuits will be used, connect the

Trig 1 Trigger

jack on the 5.0 to the Trigger Input on the amplifier

using a connection cord with mono 3.5mm mini-plugs at both ends. Follow the switch setting
instructions for the amplifiers, if any, as detailed in the amplifier owner’s manual.

Important Note:

To avoid unwanted hum and noise, be careful to keep audio connections, par-

ticularly those for amplifiers, separated from AC power cords. Do not coil extra lengths in either
audio interconnects or speaker cables.

8. Connect all speakers to the amplifiers in accordance with the instructions supplied by the manufac-
turers. Make certain that all speaker connections are made with special attention to proper polarity.

9. Install four AAA batteries in the remote. Open the battery cover on the back of the remote by
sliding the cover down and towards you. Be careful to install the batteries so that they match the
polarity (+ and

–

) indications inside the battery compartment.

10. Connect all devices, including the 5.0, to their AC power source.

11. Press the small

On/Off

button on the front panel of the 5.0 (below the large

Standby

button)

in until it clicks and catches. It will remain in and flush with the unit’s front panel. Note that
the word

will briefly flash in blue and then go out, and a small green indicator

will illuminate.
