2BChapter 3: Network and streaming configuring
20 TruVision Outdoor IP Camera User Manual
configuration window. The Local configuration window appears. See Figure 6 on
page 20.
The camera is shipped with on-screen display (OSD) menus in English only.
Figure 6: Example of a configuration window (Local configuration shown)
Configuration panel Menu window Current user displayed Exit system
Save changes
There are two main folders in the configuration panel:
 Local configuration
 Remote configuration
Local configuration
Use the Local menu to manage the network type, display mode and local storage
paths. In the Configuration panel, click “Local configuration” to display the Local
settings window. See Figure 6 and Table 2 for descriptions of the different menu
parameters.
Table 2: Overview of the Local configuration window
Parameters Description
Protocol type Specifies the network protocol used.
Options include: TCP and UDP.
Stream type Specifies the streaming method used.
Options include: Main stream and sub stream. Main is default.
Display mode Specifies the width/height ratio of the image.
Options include: Full screen, 4:3, 16:9 or adjustable.
Package file size Specifies the maximum file size.
Options include: 128 MB, 256 MB and 512 MB
