Wireless ShatterPro Acoustic Sensor Installation Instructions

Specifications

Operational voltage

584503-W

584509-W

2.8 to 4.5 VDC

6 to 16 VDC

Current draw

584503-W

584509-W

17uA typical average

23 uA typical average, 5 mA w ith LED
momentarily on

Alarm duration

Four seconds

Output

584503-W

584509-W

Normally closed output and normally open
output w ith open drain MOSFETs; 700 Ohm
max. closed resistance; 10 Mohm min. open
resistance. Output voltage must be less than
or equal to supplied battery voltage

Normally low output w ith NPN transistor and
10M pull-up resistor and normally high output
w ith PNP transistor to pow er + 16 VDC max.
output voltage

RF immunity

20 V/m, 1 MHz to 1000M Hz

Microphone

Omnidirectional electret

Recommended glass
thickness

Plate

Tempered

Wired

Laminated

3/32 to 1/4 in. (2.4 to 6.4 mm)

1/8 to 1/4 in. (3.2 to 6.4 mm)

1/4 in. (6.4 mm)

1/8 to 1/4 in. (3.2 to 6.4 mm)

Operating temperature 14 to 120°F (-10 to 50°C)

Dimensions

4.25 x 3.13 x 1.70 in (108 x 80 x 43 mm)

Housing material

Flame-retardant ABS

Color

White

Wiring

22 AWG UL stye 1061, CSA T2, color-coded
w ire, passes VW-1 flame test

Note: The 584503-W typically w orks dow n to 2.1 VDC and the
584509-W typically w orks dow n to 3.0 VDC, w hich allow s most
transmitters to send low battery trouble alarms.

FCC compliance

This equipm ent has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the

FCC rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions may cause harmful

interference to radio communications. There is no guarantee

that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment on and off, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit different

from the one where the receiver is connected.

Consult the dealer or an experienced radio/TV technician

for help.

Under FCC rules, Part 15 for Class B digital devices, operation

is subject to the following conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,

including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to

operate the equipment.

Product ordering

Product

Description

584503-W

Wireless ShatterPro, 3-V model w ith optional bracket

584509-W

Wireless ShatterPro, 9-V model w ith optional bracket

Accessories

5709C-W

Glassbreak hand-held tester, w hite

Contact information

www.utcfireandsecurity.com

or

www.interlogix.com

For customer support, see

www.interlogix.com/customer-

support
