NX-8 Control
55
APPENDIX 3 EXPANDER NUMBERS FOR REPORTING EXPANDER TROUBLE
The tables below list the device numbers that will be reported for trouble conditions.
Device Device # reported
NX-8 Control Panel 0 See page 54 for possible report codes.
NX-534E Two Way Listen-In 64
NX-540E “Operator” 40
NX-591E Cellemetry Interface 76
NX-870E Fire Supervision 9
KEYPADS
KEYPAD PART 1 PART 2 PART 3 PART 4 PART 5 PART 6 PART 7 PART 8
1 192 193 194 195 196 197 198 199
2 200 201 202 203 204 205 206 207
3 208 209 210 211 212 213 214 215
4 216 217 218 219 220 221 222 223
5 224 225 226 227 228 229 230 231
6 232 233 234 235 236 237 238 239
7 240 241 242 243 244 245 246 247
8 248 249 250 251 252 253 254 255
HARDWIRE EXPANDER (NX-216) OUTPUT MODULE (NX-508E)
Starting zone number Expander # reported Address & Dip Switch Setting
Zone 9 (All switches off) 22 24 (Switch 1 & 2 on)
Zone 9 (Switch 1 on) 23 25 (Switch 3 on)
Zone 17 (Switch 2 on) 16 26 (Switch 1 & 3 on)
Zone 25 (Switch 1 & 2 on) 17 27 (Switch 2 & 3 on)
Zone 33 (Switch 3 on) 18 28 (Switch 1,2,&3 on)
Zone 41 (Switch 1 & 3 on) 19 29 (All switches off)
30 (Switch 1 on)
31 (Switch 2 on)
WIRELESS RECEIVER (NX-448E) REMOTE POWER SUPPLY (NX-320E)
Switch Setting Expander # reported Address & Dip Switch Setting
All switches off 35 84 (All switches off)
Switch 1 on 36 85 (Switch 1 on)
Switch 2 on 37 86 (Switch 2 on)
Switches 1 & 2 on 38 87 (Switch 1 & 2 on)
Switch 3 on 39 88 (Switch 3 on)
Switches 1 & 3 on 32 89 (Switch 1 & 3 on)
Switches 2 & 3 on 33 90 (Switch 2 & 3 on)
Switch 1, 2 & 3 on 34 91 (Switches 1, 2, & 3 on)
