Page 91
C
HAPTER
7. I
NSTALLING
I
NTEL
D
IALOGIC
B
OARD
D
RIVERS
7-19
To specify a-law format for DSIx boards
1.
From the Start menu, choose
Programs > Intel(R) MEA Boards > Configuration
Manager
. The Intel MEA Configuration main dialog box opens, displaying the digital
station boards installed on the TeleVantage Server.
2.
Right click the first digital station board, and then click
Configure Device
to open the
Configuration Properties dialog box.
3.
On the Telephony tab, select the
Digital Telephony Media Type
parameter at the top
of the dialog box. Then, select
aLaw
from the
Value
drop-down list.
4.
Click the TDM Bus Configuration tab. Select the
Media Type (User Defined)
parameter at the top of the dialog box. Then, select
aLaw
from the
Value
drop-down
list.
5.
Click
OK
to save your changes.
6.
Repeat steps 2-4 for any other digital station boards installed in the TeleVantage
Server.
Go to the next section.
Board-specific configuration tasks
Depending on the boards in your system or your location, you may need to perform one or more
of the following additional tasks. See the referenced pages for details.
Important:
Trunks require additional configuration steps using the TeleVantage Administrator.
For more information, see Administering TeleVantage, Chapter 5, “Managing Trunks and Spans.”
Board
Task
All ISA boards:
Set ISA Bus Width.
See page 7-20.
Analog trunk boards:
Configure for best audio quality when forwarding
calls.
See page 7-21.
ISDN PRI T1 or
ISDN PRI E1 trunk boards:
Specify the ISDN protocol to use.
See page 7-22.
Configure Calling Name Identification.
See page 7-24.
Enable Information Element (IE) based audio
connection.
See page 7-24.
Configure delivery of overlapped DNIS digits.
See page 7-24.
ISDN BRI trunk boards:
Enable Information Element (IE) based audio
connection.
See page 7-25.
Configure delivery of overlapped DNIS digits.
See page 7-25.
Use Point-to-Point protocol.
See page 7-26.
Robbed Bit T1 boards:
Configure for extended superframe service.
See page 7-26.
