background image

Chapter 1: Introduction

4

GE-DSG-8 DSGH-5 and 8 Ethernet Switch User Manual

Product Specifications

Model

GE-DSGH-5 GE-DSGH-8 GE-DSG-8

Hardware Specification

10/100/1000Base-T Ports

5 8 8

Installation

DIN rail kit and wall mount ear

Dimension (W x D x H)

5.31 x 3.42 x 1.26 inch / 135 x 87 x 32mm

Weight (lbs)

1.0 lbs

1.045 lbs

1.045 lbs

EFT

6KV

ESD

6KV

Electronic Specification

Power Input

12~48 VDC, Redundant power

Power Consumption

11.9 Watts / 40BTU

13.2 Watts / 45BTU

13.2 Watts / 45BTU

Power Connector

6-pin removable
screw terminal

Switch Specification

Switch Processing Scheme

Store-and-Forward

Address Table

8K entries

Buffer

176 kilobytes

Flow Control

Back pressure for half duplex,
IEEE 802.3x Pause Frame for full duplex

Switch fabric

10Gbps 16Gbps 16Gbps

Throughput
(Packet per second)

7.44Mpps@64bytes

11.9Mpps@64bytes

11.9Mpps@64bytes

Jumbo Frame

9Kbytes

Network cables

10/100/1000Base-T:
Cat. 3, 4, 5, 5e, 6 UTP cable (100meters, max.)
EIA/TIA-568 100-ohm STP (100meters, max.)

Environment Specification

Operating Temperature

-40°C ~75°C

-40°C ~75°C

-10°C ~60°C

Operating Humidity

5% ~ 95% (non-condensing)

Storage Temperature

-40°C ~85°C

-40°C ~85°C

-40°C ~85°C

Storage Humidity

5% ~ 95% (non-condensing)

Standards Conformance

Standards Compliance

IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Full-duplex flow control

Stability testing

IEC60068-2-32 (Free fall),
IEC60068-2-27 (Shock),
IEC60068-2-6 (Vibration)
