Chapter 1: Introduction
2 GE-DSG-8 DSGH-5 and 8 Ethernet Switch User Manual
How to use this Manual
This User Manual is structured as follows:
Section Section Content
INTRODUCTION Product description with features and specifications
INSTALLATION
Explains the features/functions of the Industrial Gigabit Ethernet Switch,
and how to physically install the Industrial Gigabit Ethernet Switch
APPLICATION Explains the Industrial Gigabit Ethernet Switch application
SWITCH OPERATION Explains the Industrial Gigabit Ethernet Switch transmit operation
TROUBLESHOOTING Describes how to troubleshoot the Industrial Gigabit Ethernet Switch
APPENDIX A Contains cable information for the Industrial Gigabit Ethernet Switch
Product Features
Physical Port
• 5-Port 10/100/1000Base-T RJ-45 with auto MDI/MDI-X function (GE-DSGH-5)
• 8-Port 10/100/1000Base-T RJ-45 with auto MDI/MDI-X function (GE-DSG-8 / GE-
DSGH-8)
Layer 2 Features
• Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab
1000Base-T Ethernet standard
• Supports Auto-negotiation and 10/100Mbps half / full duplex and 1000Mbps full
duplex mode
• High performance Store and Forward architecture, broadcast storm control,
runt/CRC filtering eliminates erroneous packets to optimize the network
bandwidth
• Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE
frame flow control (Full-Duplex)
• Integrated address look-up engine, support 8K absolute MAC addresses
• 9K Jumbo packet size support
• Automatic address learning and address aging
