GE-DSG-8 DSGH-5 and 8 Ethernet Switch User Manual

19

Appendix A

Network Connection

Switch's RJ-45 Pin Assignments

1000Mbps, 1000Base-T

Contact

MDI

MDI-X

1 BI_DA+ BI_DB+

2 BI_DA- BI_DB-

3 BI_DB+ BI_DA+

4 BI_DC+ BI_DD+

5 BI_DC- BI_DD-

6 BI_DB- BI_DA-

7 BI_DD+ BI_DC+

8 BI_DD- BI_DC-
