IC Realtime Combo Series: 8 Channel DVR with built-in 19 LCD monitor User Manual
Page 119
110
Figure 7-50
Please refer to the following sheet for detailed information.
Parameter Function
Event
Type
z
The abnormal events include: no disk, no space, disk error, net error.
z
You need to draw a circle to enable this function.(Multiple choices)
Normal
Out
The corresponding alarm activation output channel when alarm occurs,
There are three channels.
Latch
The alarm output can delay for the specified time after alarm stops.
Then system disables alarm and corresponding activation output.
The value ranges from 10s to 300s.
Send
email
If you enable this function, system can send out email to alarm the
specified user.
Alarm
upload
System can upload the alarm signal to the network (including the alarm
centre.)
Show
message
System can display alarm information in local combo DVR screen.
7.3.4 Additional
Function
7.3.4.1 DNS
Here you can set server or local operator DNS address. See
X478H478H478H
Figure 7-51
