23 HMXE8501 .... Swashplate ........................................1
24 HMXE8512 .... Mixing Arms .....................................16
25 HMXE8502 .... Washout Base ...................................1
26 HMXE8503 .... Main Shaft .........................................1
27 HMXE8504 .... Seesaw Bushing Set .........................2
28 HMXE8505 .... Spindle Bolt Set .................................1
29 HMXE8506 .... Blade Grip Bolt Set ............................1
30 HMXE8507 .... Main Blade Grips ...............................1
31 HMXE8508
.... Dampening Shims .............................1
32 HMXE8827 .... Bearings Main Grips ..........................6
33 HMXE8509
.... Head Dampeners ..............................4
34 HMXE8510 .... Feathering Spindle ............................1
35 HMXE8511 .... Head Block ........................................1
36 HMXE8512 .... Mixing Arms .......................................2
37 HMXE8513 .... Seesaw ..............................................1
38 HMXE8514 .... Flybar Control Set ..............................1
39 HMXE8515
.... Flybar .................................................1
40 HMXE8516 .... Flybar Paddles ...................................2
41 HMXE8517 .... Control Ball Set ................................26
42 HMXE8519 .... Washout Control Arms ......................2
43 HMXE8518
.... Swashplate Stay ................................1
44 HMXE8027 .... Tail Belt Drive Gear ............................1
45 HMXE8336 .... Tail Boom Support .............................2
46 HMXE8637 .... Tail Rotor Linkage ..............................1
47 HMXE8638 .... Tail Servo Mounts ..............................2
48 HMXE8639
.... Tail Boom ...........................................1
49 HMXE8640 .... Horizontal Fin Mount .........................1
50 HMXE8641
.... Horizontal Fin ....................................1
51 HMXE8642 .... Vertical Fin .........................................1
52 HMXE8643 .... Tail Rotor Gear Case .........................1
53 HMXE8644 .... Tail Belt Pulley ...................................1
54 HMXE8645 .... Tail Rotor Shaft Assembly..................1
55 HMXE8646 .... Tail Rotor Control Arm .......................1
56 HMXE8647 .... Tail Pitch Slider Control Set ...............1
57 HMXE8648 .... Tail Rotor Hub ....................................1
58 HMXE8649 .... Tail Rotor Grips ..................................1
59 HMXE8426 .... Tail Rotor Blades ...............................2
60 HMXE8323 .... Main Rotor Blades .............................2
61 HMXM2009
... Brushless ESC ..................................1
62 HMXE8650 .... Tail Rotor Drive Belt ...........................1
HMXE7384 .... Canopy Green RXR ...........................1
HMXE7385 .... Canopy White ...................................1
HMXE8029 .... Main Rotor Gear without One-Way
Bearing ...............................................1
OPTIONAL PARTS
Stock # ................. Description
HMXE7493 .... CNC Mixer Arms (2) AXE 400
HMXE7483 .... CNC Head Block AXE 400
HMXE7482 .... CNC Main Blade Grips (2) AXE 400
HMXE7487 .... CNC Seesaw AXE 400
HMXE7484 .... CNC Flybar Carrier AXE 400
HMXE7485 .... CNC Washout Arms (2) AXE 400
HMXE7486 .... CNC Washout Base AXE 400
HMXE7488 .... CNC Swashplate AXE 400
HMXE7489 .... CNC Tail Case AXE 400
HMXE7490 .... CNC Tail Drive Belt Pulley AXE 400
HMXE7491 .... CNC Counter Drive Belt Pulley AXE 400
HMXE7492 .... CNC Tail Blade Grips (2) AXE 400
HMXE7494 .... CNC Tail Servo Mount (2) AXE 400
HMXE7495 .... CNC Boom Support Ends (4) AXE 400
HMXE7496 .... CNC Boom and Fin Clamp AXE 400
HMXE7497 .... CNC Head Button AXE 400
HMXE7498 .... Carbon Fiber Vertical Fin AXE 400
HMXE7499 .... Carbon Fiber Horizontal Fin AXE 400
