7
STICK CONTROLS
Throttle/Collective
Tail (rudder)
Left and right cyclic
Forward and back cyclic
It’s also important to know that your TX610 transmitter is capable of a system
reset. (See how this is done in the TX610 Manual) If you decide to do a system
reset, the factory setup numbers to the Heli-Max AXE 100 CP are listed here.
Below are the factory setup parameters for your AXE 100 CP Helicopter.
TX610 1 2 3 4 5 6
Servo Reverse NOR NOR REV NOR NOR NOR
Dual Rates 80/100 80/100 80/100
Exponential -20 -20 0
Sub Trims 0 0 0
Normal Throttle 0 45 75 92 100
Normal Pitch 40 45 55 70 75
UP-1 Throttle DIAL
UP-1 PITCH 30 42 55 65 75
Gyro 35 NON HH 75 HH
Swashplate Type 90deg
