Surface-Lit AccuTab 30
AccuTab Specifications
Dimensions/Weight
(AccuTab)
Active Area
24” x 36”
36” x 48”
42” x 60” Footprint
32.75” x 46”
44.5” x 60”
52.5” x 68” Weight
26 lbs.
40 lbs.
55 lbs. Avg. Ship Wt.
45 lbs.
71 lbs.
104 lbs.
Dimensions/Weight
(Surface-Lit AccuTab)
Active Area
20” x 24”
24” x 36”
36” x 48” Footprint
31” x 36”
35” x 48”
47” x 63” Weight
50 lbs.
68 lbs.
102 lbs. Avg. Ship Wt.
70 lbs.
90 lbs.
130 lbs.
Technology
Patented electromagnetic
Resolution
Up to 4000 lpi or 150 lpmm real resolution
Absolute Accuracy
(certified)
±0.005 in / ±0.127 mm (Standard)
±0.002 in / ±0.051 mm (Standard)
±0.003 in / ±0.076 mm (Standard)
±0.0075 in / ±0.190 mm (Standard)
Repeatability
1 LSB (least significant bit)
Proximity
AccuTab: 1.0” (25.4 mm) nominal
Surface-
Lit AccuTab: 0.5” (13 mm) nominal
Self-Diagnostics
Automatic testing, drive electronics and microprocessor
Operating Modes Point, line, continuous, line incremental, continuous incremental
and remote request
Baud Rate
Up to 38,400
Power Supply
100/120/220/240 VAC, 50/60 Hz
Operating Temperature
41 to 115°F/5 to 46°C
Humidity Range
10 to 95%, noncondensing
Storage Temperature
0 to +150°F/-18 to +68°C
Altitude Range
0 to 10,000 ft./0 to 3,077 m
Certifications
UL, CSA, FCC-B, VDE-B, CE
Cursor Switches
Elastomeric keypad, rated life over 1 million actuations
Output Formats GTCO T5/5A Binary and ASCII, CalComp 3400, Summagraphics
