Great Planes Fun One 40 - GPMA0490 - Manual (Page 40)

PART# QTY. DESCRIPTION
ITEMS PACKED INDIVIDUALLY
FUN1P01
FUN1P02
CANPY047
DECAL001
L-6U
MM19D90
PLTB011
PTUBE001
WIRES16
WIRES17
FUN1F10
FUN1F15
FUN1F16
FUN1F22
1
1
1
1
1
1
2
2
2
2
1
1
1
1
Fuselage and Wing Plan
Instruction Book
Clear Canopy
Great Planes Decal
Landing Gear
Motor Mount
Plastic Outer Pushrod Tube 24"
1/2x 7-7/8 x.030 Paper Tube
Threaded Pushrod Wire (12")
Threaded Pushrod Wire (34")
Balsa 3 / 1 6 x 3 x 3 - 3 / 4 Hatch
Balsa 3/16 Turtle Deck Top
Balsa 1/16 Turtle Deck Sheeting
Balsa 1/8 Middle Bottom Sheet
SUB-PACK DIE-CUT PLYWOOD PARTS (FUN1A01)
PART QTY. DESCRIPTION
FUN1W08
FUN1W10
FUN1W11
1
2
4
Balsa 3/8 Shaped TE Set
Balsa 7/16 Shaped Aileron
Balsa 1/16 Wing Sheeting
SUB-PACK LONG STICKS (FUN1A07)
BAL143
FUN1S01
FUN1S02
FUN1S04
FUN1W09
2
3
1
1
4
Balsa Triangle 1/4x30
Balsa 1/4 Stab/Fin Frame
Balsa 1/4 Stab/Fin Ribs
Balsa 1/4 Stab/Fin Ends
4 Balsa 1/4 x 3/8 x 28 Spar
SUB-PACK SMALL WOOD PARTS (FUN1A09)
DOWEL037
FUN1F11
FUN1F12
FUN1F13
FUN1F17
FUN1F18
FUN1F19
FUN1F20
FUN1F21
FUN1W13
FUN1W15
FUN1W16
2
1
1
1
1
1
2
1
1
1
1
4
1/4Dia.x 5-3/4 Dowel
Balsa 3/16 Hatch Front
3-Ply 1/16 Hatch Hold Down
5-Ply Landing Gear Plate
Basswood 1/4 Hatch Hold Down Block
5-Ply 1/4 Wing Bolt Block
Basswood 1/4 Servo Rail
5-Ply Shaped Firewall
Balsa 1/8 Sq. x 4 Filler
5-Ply 1/8 Shaped Wing Joiner
5-Ply 1/4 Wing Bolt Plate
Basswood 1/4 Wing Servo Rail
FUN1F06
FUN1F08
FUN1F09
FUN1W01
FUN1W06 2
1
1
2
1
Ply 1/8 DC Front Fuselage Doubler
Ply 1/8 DC Former
Ply 1/8 DC Formers & Front Bottom
Ply 1/8 DC Ribs 1A,B, D, 2A, Aligner
Ply 1/32 DC Dihedral Braces
SUB-PACK LARGE BALSA SHEETS (FUN1A02)
FUN1F02
FUN1F04
2
1
Balsa 1/8 DC Rear Fuse Side
Balsa 1/8 DC Rear Fuse Sheet
SUB-PACK HARDWARE (FUN1M02)
SUB-PACK MEDIUM BALSA SHEETS (FUN1A03)
FUN1F01
FUN1F03
FUN1F05
FUN1F07
2
2
1
1
Balsa 1/8 DC Lower Fuse Front
Balsa 1/8 DC Upper Frt. Side/Can. Base
Balsa 3/32 DC Rear Fuse Doubler
Balsa 3/32 DC Misc. Fuse Parts
SUB-PACK MEDIUM WOOD PARTS (FUN1A08)
FUN1F14
FUN1S03
FUN1W17
6
1
4
B a l s a 1 / 8 x 3 / 1 6 x 18 Stringers
Basswood 1/8 Stab Brace
Balsa 1/8 x 3/8 x 15 Spar Doubler
SUB-PACK SMALL BALSA SHEETS (FUN1A04)
FUN1W12
FUN1W14 4
2
Balsa 1/16 Wing Center Sheet
Balsa 3/32 Shear Web Sheet
SUB-PACK DIE-CUT BALSA RIBS (FUN1A05)
FUN1W02
FUN1W03
FUN1W04
FUN1W05
2
2
2
2
Balsa 1/8 DC Ribs 1 C , 2 B & 2 C
Balsa 3/32
Balsa 3/32
Balsa 3/32
DC
DC
DC Ribs 3 & 4
Ribs 5, 7 & 8
Ribs 6,9 & 10
SUB-PACK LONG WING PARTS (FUN1A06)
FUN1S05
FUN1W07
1
1 Balsa 1/4 Shaped Elevator
Balsa 3/8 Shaped LE Set
NUTS001
NUTS010
NYLON02
NYLON13
NYLON16
NYLON17
NYLON20
NYLON21
NYLON53
PLTB014
SCRW002
SCRW004
SCRW005
SCRW020
SCRW024
SCRW031
SCRW052
SCRW055
WBNT075
WBNT128
WBNT145
WBNT153
WHCL005
WSHR005
6
4
4
2
1
4
2
2
1
1
8
4
1
1
2
2
4
2
1
1
1
1
2
4
4-40 Blind Nut
6-32 Hex Nut
Nylon Control Horn
Nylon 1/4-20 x 2 Bolt
Nylon 5/32 Steering Arm
Nylon Clevis
Nylon Non-Threaded Swivel
Nylon Clevis
Nifty Hinges - Strip of 20
Yellow Inner Pushrod Tube 4-1/4"
2-56 x 5/8 Machine Screw
#4x 1/2 Sheet Metal Screw
6-32 x 1/8 Socket Head Set Screw
6-32 x 1/4 Machine Screw
#2 x 3/8 Pan Head Screw
4-40 3/8 Round Head Screw
4-40 x 5/8 Machine Screw
6-32 x 1-1/2 Socket Head Screw
Nose Gear
Tail Gear
Elevator Joiner
Aileron Torque Rods (L & R)
Wheel Collar 5/32
#4 Flat Washer
