Great Planes Revolver GP/EP ARF 59" - GPMA1018 - Manual (Page 4)

Propeller
If you are installing a glow engine, choose a prop based
on the engine manufacturer’s recommendation. If you are
installing the recommended RimFire brushless motor, we
suggest an APC 11x5.5 Electric Propeller (APCQ1055).
Batteries and Charger
For a brushless motor installation, two 3200mAh 11.1V
Lithium Polymer battery packs connected in series are
recommended. Order numbers for the battery packs and
series connector are provided below:
❏
Great Planes LiPo 3200mAh 11.1V 20C Discharge
w/Balance (GPMP0623)
❏
Great Planes Series Deans U 2 to 1 Adapter (GPMM3143)
A cell balancer is required for the LiPo battery pack listed above:
❏
Great Planes ElectriFly ™ Equinox ™ LiPo Cell Balancer 1-5
(GPMM3160)
A suitable charger is also required. The Great Planes
PolyCharge4
™ is designed for LiPo packs only, but is able
to charge four LiPo packs simultaneously. The Great Planes
Triton2
™ charger will only charge one pack at a time, but is
capable of charging NiCd, NiMH, LiPo, and lead acid batteries.
Order numbers for both are provided below:
❏
Great Planes PolyCharge4 DC Only 4 Output LiPo
Charger (GPMM3015) or Great Planes ElectriFly Triton2
DC Comp Peak Charger (GPMM3153)
ADDITIONAL ITEMS REQUIRED
This is the list of hardware and accessories required to fi nish the
Revolver ARF. Order numbers are provided in parentheses:
❏
R/C Foam Rubber (1/4" [6mm], HCAQ1000; or
1/2" [13mm], HCAQ1050)
❏
3' [900mm] Standard Silicone Fuel Tubing (GPMQ4131)
Adhesives and Building Supplies
This is the list of Adhesives and Building Supplies that are
required to fi nish the Revolver ARF:
❏
1/2 oz. [15g] Thin Pro CA (GPMR6001)
❏
1/2 oz. [15g] Medium Pro CA+ (GPMR6007)
❏
Pro 30-Minute Epoxy (GPMR6047)
❏
Masking Tape (TOPR8018)
❏
Threadlocker Thread Locking Cement (GPMR6060)
❏
Denatured Alcohol (for epoxy clean up)
❏
Drill bits: 1/16" [1.6mm], 5/64" [2mm], 3/32” [2.4mm]
❏
Great Planes Tap & Drill Set 6-32 (GPMR8102, Glow
Engine Installation Only)
❏
Tap Handle (GPMR8120)
❏
Small Metal File
❏
#1 Hobby Knife (HCAR0105)
❏
#11 Blades (5-pack, HCAR0211)
❏
Medium T-pins (100, HCAR5150)
❏
Top Flite ® MonoKote ® Sealing Iron (TOPR2100)
❏
Top Flite Hot Sock ™ Iron Cover (TOPR2175)
❏
220 grit Sandpaper
❏
1/2" [13mm] Double-sided Foam Mounting Tape
(GPMQ4440, Brushless Installation Only)
❏
Microballoons (TOPR1090)
❏
Panel Line Pen (TOPQ2510)
Optional Supplies and Tools
Here is a list of optional tools that will help you build the
Revolver ARF:
❏
1/2 oz. [15g] Thick Pro CA- (GPMR6013)
❏
2 oz. [57g] Spray CA Activator (GPMR6035)
❏
4 oz. [113g] Aerosol CA Activator (GPMR6034)
❏
CA Applicator Tips (HCAR3780)
❏
CA Debonder (GPMR6039)
❏
Pro 6-Minute Epoxy (GPMR6045)
❏
Epoxy Brushes (6, GPMR8060)
❏
Mixing Sticks (GPMR8055)
❏
Mixing Cups (GPMR8056)
❏
Pliers with Wire Cutter (HCAR0630)
❏
Hobbico Duster Compressed Air (HCAR5500)
❏
Switch & Charge Jack Mounting Set (GPMM1000)
❏
Rotary Tool such as Dremel
❏
Rotary Tool Reinforced Cut-Off Wheel (GPMR8020)
❏
Servo Horn Drill (HCAR0698)
❏
Hobby Heat Micro Torch (HCAR0750)
❏
Dead Center ™ Engine Mount Hole Locator (GPMR8130)
❏
Precision Magnetic Prop Balancer™ (TOPQ5700)
❏
AccuThrow Defl ection Gauge (GPMR2405)
❏
CG Machine ™ (GPMR2400)
❏
Hobbico Flexible 18" Ruler Stainless Steel (HCAR0460)
❏
Top Flite MonoKote Trim Seal Iron (TOPR2200)
❏
Top Flite MonoKote Heat Gun (TOPR2000)
❏
Hobbico Pin Vise 1/16 Collet w/6 Bits (HCAR0696)
❏
Hobbico 8-Piece Ball Tip Hex L Wrench SAE (HCAR0520)
❏
Hobbico 7-Piece Ball Tip Hex L Wrench Metric (HCAR0521)
❏
Great Planes Clevis Installation Tool (GPMR8030)
4
