11
❏
3. Secure the wing tube to the fuselage using a #4 x 1/2"
[13mm] self-tapping screw.
❏
4. Test fi t the nylon wing bolts into the blind nuts in the
wing panels. If the bolts are diffi cult to thread into the blind
nuts, insert a 1/4-20 tap into the nuts to clean up the threads.
❏
5. Install the wing panels onto the wing tube and secure
them to the fuselage using two nylon wing bolts.
BUILD THE FUSELAGE
Assemble the Tail Section
❏
1. Slide the horizontal stabilizer into the stab slot at the
aft end of the fuselage. Center the stab left and right in the
fuselage. Measure the distance from the stab tips to the wing
tips and make the measurements equal. When satisfi ed, use a
felt-tip pen to trace around the stab where it meets the fuse.
❏
2. Trim the covering from the stab 1/16" [1.6mm] inside
the lines you drew.
