10
❏
3. Slide the landing gear into the slots in both sides of the
fuselage and place the aluminum doubler onto the landing
gear. Secure the doubler and the landing gear to the fuselage
with ten #6 x 3/4" [19mm] socket head cap screws, #6 lock
washers and #6 flat washers. Apply a drop of thread locker
to each of the screws. NOTE: The landing gear will have a
slight forward sweep when installed correctly.
Install the Stabilizer and Rudder
❏
1. Locate the stabilizer and vertical fin. Test fit them in
place on the back of the fuselage.
❏
2. Use a felt tip pen to outline the fin on the top of the
stabilizer and to outline the fuselage on the bottom of the
stabilizer.
