Chapter 5: Local Management
5-66 2E48-27R/2E49-27R User’s Guide
3. Use the arrow keys to highlight the SAVE command at the bottom of
the screen.
4. Press ENTER. The message “SAVED OK” displays.
5.18.2 Setting the Reset Peak
To set the Reset Peak field to YES or NO, proceed as follows:
1. Use the arrow keys to highlight the Reset Peak field for the selected
port.
2. Press the SPACE bar to select YES or NO.
3. Use the arrows keys to highlight the SAVE command at the bottom of
the screen.
4. Press ENTER. The message “SAVED OK” displays and the Time
Since Peak field is also reset.
5.19 DEVICE STATISTICS MENU SCREEN
The Device Statistics Menu screen, Figure 5-27 , provides access to
screens that allow the user to obtain switch statistics about frame traffic
through each port and view operating statistics about each port.
To access the Device Statistics Menu from the Device Menu screen, use
the arrow keys to highlight the DEVICE STATISTICS menu item and
press ENTER. The Device Statistics Menu
screen displays.
NOTE
The SWITCH STATISTICS menu item on the Device Statistics
Menu screen will not display if the operational mode of the
device is set to SECURE FAST VLAN:
