GME TX3520 - Manual (Page 5)

t X 3 5 1 0 / t X 3 5 2 0 / t X 3 5 4 0 I n s t r u c t I o n m A n uA l PA G E 5
• High Contrast Liquid Crystal Display: Fully detailed lcD
provides a visual indication of the selected channel and all
selected functions at a glance.
• User Programmable Receive-Only Channels: use the
radio’s front panel controls to program up to 95 of your own
receive-only channels (in 5 banks of 19 channels) within the
403-520 mHz frequency range.
• In-Built CTCSS & DCS: user selectable continuous tone
coded squelch and Digital coded squelch system option
provides silent channel operation on individual channels.
• In-Built Selcall with QUIET Mode: Provides selective
calling of individuals or groups with fully user-adjustable
5 tone transmitted selcall Ident. Also allows alphanumeric
naming of up to 10 Idents for easier caller identification.
• User selectable Wide/Narrow Receive Filter
• Dual Microphone Input Sockets: Front and rear
microphone sockets to match most installation needs. Both
sockets can be used independently or simultaneously.
• Over Voltage Protection: special overvoltage detection
circuitry protects the radio and warns of excessive voltage
conditions by flashing the display.
• Surface Mount Technology: the very latest surface
mount component types, design and assembly techniques
and quality control procedures are used to ensure the
highest performance and reliability.
• Designed and Manufactured in Australia: totally
designed and manufactured in Gladesville to meet the
demanding needs of the Australian community.
TX3510/TX3520 FRONT PaNEL CONTROLS
GENERaL OPERaTIONS
Volume control liquid crystal Display channel switch
Push for squelch level/
Priorty channel
menu/
Function
scan/
os-Gs
Quiet/
Duplex
squelch/
Alpha
Front mic Input
PUSH
PRIORITY
MENU
F PUSH
SQL LVL
SCAN
OS/GS
QUIET
DUP
SQL
ALPHA
