Prior to operation
Receiver R113F
Crystal
Antenna
Output Connector
“1”: Steering Servo (Ch1)
“2”: Throttle Servo (Ch2)
“3”: CH3 Servo (CH3)
Power Connector
Servo S3003
Servo Horn
Mounting Flange
To Receiver
The following accessories are sup-
plied with the system;
-Spare servo horns: Use to match
your application.
-Servo mounting hardware: Rubber
bushing, grommet, wood screws.
(For mounting precautions see
pages 15.)
Electronic speed control MC210CB
1
2
3
B/C
FP-R113F
FM
Connects
to Motor
Connects
to Battery
Power
switch
Connects
to Receiver
Monitor Lamp
Neutral Point Trim
High Point Trim
MC 210CB
ON OFF
