Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721, but
full retail prices and shipping and handling charges will apply.
Illinois and Nevada residents will also be charged sales tax. If
ordering via fax, include a Visa

®

or MasterCard

®

number and

expiration date for payment.

Mail parts orders Hobby Services
and payments by 3002 N Apollo Drive, Suite 1
personal check to: Champaign IL 61822

Be certain to specify the order number exactly as listed in the
Replacement Parts List. Payment by credit card or personal
check only; no C.O.D.

If additional assistance is required for any reason contact
Product Support by e-mail at productsupport@fl yzoneplanes.
com, or by telephone at (217) 398-8970.

CONTENTS

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

Fuselage

Left Wing

Right Wing

Main Landing Gear

Float Brackets

Wing Struts

Vertical Stabilizer

Hardware

Propeller/Spinner Assembly

Top Hatch

Horizontal Stabilizer

Floats

1

6

7

2

4

8

9

10

11

12

3

7

5

REPLACEMENT PARTS LIST

ORDER NO. DESCRIPTION

Fuselage Set
Wing Set
Horizontal Stab
Vertical Fin
Main Landing Gear
Tail Wheel Set
Cowl
12x6 Propeller
Spinner
Prop Adapter
Float Set
Float Brackets

F L Z A 6 2 6 5
F L Z A 6 2 6 6
F L Z A 6 2 6 7
F L Z A 6 2 6 8
F L Z A 6 2 6 9
F L Z A 6 2 7 0
F L Z A 6 2 7 1
F L Z A 6 2 7 2
F L Z A 6 2 7 3
F L Z A 6 2 7 4
F L Z A 6 2 7 5
F L Z A 6 2 7 6

ORDER NO. DESCRIPTION

Water Rudders
Wing Clips
Hatch Set
41-19-850 Motor
40 Amp ESC
Main Wheels
Servo
Wing Strut Set
Decal Sheet
Flyzone LiPo Battery 3S 11.1V 1800mAh 20C
Tactic TTX600 6Ch SLT 2.4GHz Radio System No Servos
Tactic TR624 6-Channel SLT 2.4GHz Receiver
Great Planes AC/DC 3S LiPo Balancing Smart Charger

F L Z A 6 2 7 7
F L Z A 6 2 7 8
F L Z A 6 2 7 9
F L Z A 6 2 8 0
F L Z A 6 2 8 1
F L Z A 6 2 8 2
F L Z A 6 2 8 3
F L Z A 6 2 8 4
F L Z A 6 2 8 5
F L Z A 6 0 2 4
TA C J 2 6 0 0
TA C L 0 6 2 4
GPMM3318
