Flyzone FLZA3904 - Manual

™
flyzoneplanes.com
Cathy II
P-51 Mustang
Instruction Manual
BATTERY HATCH REMOVAL
WING INSTALLATION
REQUIRED
● AirCore Power Core (FLZA6400)
● AirCore Battery (FLZA6401)
● SLT Compatible Radio System
● AirCore 2S LiPo AC/DC Charger (FLZA6411)
FLIGHT SETUP
Because transmitters other than the Tactic transmitters
may be used, the following information is included to
properly set the throws and C.G. (center-of-gravity) on
the AirCore P-51 Mustang.
The measurements are taken at the widest part of the
control surface.
Aileron Throw 1/4 in [6mm] 12 deg. Up and down
Rudder Throw 7/16 in [12mm] 18 deg. Left and right
Elevator Throw 3/16 in [5mm] 10 deg. Up and down
