LiPo Balance Charger
Instruction Manual
INTRODUCTION
The AirCore LiPo Battery Charger is great for simple balance
charging of 2-cell lithium-polymer batteries for small electric
models. Use it only to charge batteries within a capacity
range of 150 to 750 mAh.
SPECIFICATIONS
Input
voltage: 11.7 V – 15 V DC
Battery types, # cells: 2 lithium-polymer cells
connected in Series
(7.4V
LiPo)
Charge
current: 450mA maximum
Charge
method: CC-CV (current drop-off
termination)
Battery
capacity: 150 –750 mAh
Status
indicator: Two LEDs;
one green, one red
Input
connectors: polarized DC power jack
for AC/DC input
Output
connectors: One 2S balance plug
Case
size: 2.18" x 1.13" x 3.26"
[55 x 28 x 82 mm]
Weight: 2.1oz. [59 g]
SPECIAL FEATURES
● A very economical, portable and simple way to
balance charge LiPo batteries
● Specifi cally designed for 2-cell 7.4V lithium-polymer
batteries only
● “Constant current/constant voltage” charge method
● Automatically starts charge upon connection of
battery to the balance plug
● 450 mA maximum charge current requires no
adjustment
● Twin LEDs indicate charging status
IMPORTANT PRECAUTIONS
● Charge only lithium-polymer (LiPo) rechargeable
batteries that are 2S (2 cells in series) 7.4V
nominal voltage, from 150 mAh to 750 mAh, which
have a balance connector.
● Do not attempt to use this charger with NiCd, NiMH
or different types of Lithium-Ion batteries as they
are not compatible!
● Do not leave the charger unattended while charging.
Disconnect the battery and remove input power
from charger immediately if either becomes hot!
However, it is normal for the charger to get warm.
● Disconnect the battery from the charger
immediately and remove to a fi reproof location if
the battery begins to swell or smoke!
● Only use the included car adapter or approved AC
adapter to power the charger.
● Do not use charger with car running.
● Do not allow water, moisture or foreign objects into
the charger.
● Do not block the air intake holes, which could
cause the charger to overheat.
● Do not place the charger or any battery on a
fl ammable surface or near a combustible material
while in use.
● Do not charge on a carpet, cluttered workbench,
paper, plastic, vinyl, leather, wood, or inside an
R/C model.
● Never charge inside a full-sized vehicle.
● Always disconnect charger from input power when
not in use.
● Do not attempt to charge a battery if it is swollen
or hot.
● Keep out of reach of children.
CHARGING BATTERIES
IMPORTANT!! ALWAYS charge a LiPo battery in a
location that is fi reproof. NEVER leave the battery
unattended while being charged! If the battery feels
warm during charge, remove the battery at once and
disconnect the charger from the power source.
Use only approved power input accessories – the
included car adapter and AC adapter.
Read this entire instruction manual to learn about specific functions and features, and safety information.
