3
We, as the kit manufacturer, provide you with a top quality,
thoroughly tested kit and instructions, but ultimately the
quality and fl yability of your fi nished model depends on how
you build it; therefore, we cannot in any way guarantee the
performance of your completed model, and no representations
are expressed or implied as to the performance or safety of
your completed model.
Remember: Take your time and follow the instructions to
end up with a well-built model.
REQUIRED FOR COMPLETION
Other than a #1 and #2 Phillips screwdriver and a few drops
of non-permanent threadlocker (GPMR6060), no adhesives
or anything extraordinary is required to assemble the Beaver.
The RTF is fully equipped with a complete radio control
system, LiPo battery and charger, so no other accessories
are required, but the following items are required to complete
the Tx-R edition:
Transmitter
The Tx-R includes the Tactic™ TR624 6-Channel 2.4GHz
receiver, so you’ll need either a Tactic TX600 6-channel 2.4GHz
transmitter, or any other 5-channel (or more) transmitter
compatible with the Tactic AnyLink™ 2.4GHz radio adapter*.
Using the AnyLink allows any compatible transmitter to work
with the Tactic receiver.
❍ TX600 6-channel transmitter (TACJ2600)
❍ AnyLink radio adapter* (TACJ2000)
*In addition to the AnyLink radio adapter, some AnyLink-
compatible transmitters may also require additional adapter
cables. Visit Tx-Ready.com to see the AnyLink compatibility
chart or contact Product Support at the contact information
on this page.
LiPo Battery
The RTF edition of the Beaver includes a Flyzone 3S (11.1V)
1800mAh 20C LiPo battery and the same is recommended for
the Tx-R, but a 2100mAh battery is also an option for slightly
longer fl ight times (more about fl ying time on page 15).
❍ Flyzone 3S (11.1V) 1800mAh 20C LiPo battery
(HCAA6430)
❍ Flyzone 3S (11.1V) 2100mAh 20C LiPo battery
(HCAA6387)
Spare batteries may also be purchased and charged at home
ahead of time, eliminating the wait between fl ights for batteries
to charge at the fi eld.
NOTE: The Flyzone batteries suggested are equipped with
a SuperTigre
® battery connector that fi t the connector on
the ESC. If using a different LiPo battery that has a Deans ®
connector, a SuperTigre-to-Deans adapter (SUPM0040) will
be required, or the battery connector on the ESC may be
replaced with a Deans Ultra Plug ® male connector which will
require soldering (but is a simple task for those so equipped).
Charger
The RTF comes equipped with a Great Planes 3S LiPo
balancing Smart Charger, but the Tx-R requires a charger to
be purchased separately. The Smart Charger is a safe way to
charge your LiPo battery, but it’s very basic and just enough
to get you started. The Smart Charger charges at a rate of .8
Amps, so it will take at least one-and-a-half hours or more to
charge your battery. For those who have the RTF and wish
to upgrade their charger, or those with the Tx-R who must
purchase a charger anyway, the Duratrax
® Onyx™ 235 AC/
DC Advanced Peak Charger (DTXP4235) is recommended.
The Onyx is perfect for 3S batteries used with the Beaver
and may be powered either by an external DC power source
(such as a 12V battery), or a 110V AC outlet. The Onyx also
has an adjustable charge rate to charge your batteries in as
little as a half-hour or less (depending on the condition of your
batteries and the manufacturer’s specifi ed charge rate). The
Onyx can also charge larger batteries and batteries other than
LiPos, so it is a versatile charger you can grow into. Finally, the
235 features an LCD digital display screen, so you can see
how much capacity it took to recharge the battery (required
for monitoring the condition of your batteries and calculating
how long you can fl y).
NOTE: For use with the Onyx 235, LiPo batteries that come
with a SuperTigre connector (such as the Flyzone batteries
recommended) require a banana plugs-to-SuperTiger charge
lead (SUPM0070). And batteries that come with a Deans Ultra
Plug connector require a Charge Lead with banana plugs/
Deans Ultra Plug Male charge lead (GPMM3148).
KIT INSPECTION
Before assembly, take an inventory of this kit to make sure
it is complete, and inspect the parts to make sure they are
of acceptable quality. If any parts are missing or are not of
acceptable quality, or if you need assistance with assembly,
contact Product Support. When reporting defective or missing
parts, use the part names exactly as they are written in the
Contents list.
Flyzone Product Support Ph: (217) 398-8970 ext. 5
3002 N Apollo Drive Suite 1 Fax: (217) 398-7721
Champaign, IL 61822
E-mail: airsupport@fl yzoneplanes.com
ORDERING REPLACEMENT PARTS
Replacement parts for the Flyzone de Havilland Beaver RTF/
Tx-R are available using the order numbers in the Replacement
Parts List that follows. The fastest, most economical service
can be provided by your hobby dealer or mail-order company.
To locate a hobby dealer, visit the Flyzone web site at www.
fl yzoneplanes.com. Click on the Storefront icon at the top
of the page to load the Flyzone Dealer Locator. Follow the
instructions provided on the page to locate a U.S., Canadian or
International dealer.
