15
Certificate of
Authenticity
2008-2009 HRM System All right reserved.
c
FingerTec TCMS v2
Product Key:
YTR1-4AWE-9899
S/N: 8203602 Activation Key: K2EWF5SZ
001010
poWer SUpply porT
Insert the Power Adapter point to this port for power.
rS232/rS485/WiegANd CoNNeCTioN porT
RS232
–
Connection to a computer using RS232 cable.
RS485 Single Connection
-
Connection to a single computer using RS485 wire.
RS485 Network Connection
-
Connection to multiple computers using Daisy Chain connection.
Wiegand Output
–
Connecting with third party connector or terminal(s).
Checking the Genuine TCMS V2
TCMS V2 is a genuine software by FingerTec. Check the genuine sticker on top of the
TCMS V2 software manual booklet to retrieve a product and activation code. The serial
number of the terminal must be a match with the serial number printed on the booklet
in order to activate the system.
Installation and Setup of TCMS V2
Install TCMS in a PC with sufficient minimum requirements. Refer to
user.fingertec.com/
user-promanual.htm
for TCMS V2 Manual online. Setup Wizard will require the product
key and activation code to activate the system. In case you lose TCMS V2 product key and
activation code, go to
user.fingertec.com/retrieve_key_user.php
for retrieval.
Connecting The Terminals to TCMS V2
deTermiNiNg TermiNAl NUmBer
Identify the number of your terminal to differentiate between one another. One TCMS
V2 can connect to 999 units of terminal. Press Menu > Options > Comm Opt > Dev Num
> Select the number.
USiNg TCp/ip
Determining the IP Address
IP address is important, as it is a unique address of the terminal in LAN. Without the IP
address, locating the specific terminal is not possible.
To input the IP address of the terminal:
Press Menu > Options > Comm Opt > IP Addr > Key in IP
address.
