JTAG-SMT1 Programming Module for Xilinx® FPGAs
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 2 of 5
TCK
JTAG SMT1 FPGA
TMS
TDI
TDO
GND
Vref VIO
TMS
TCK
TDI
TDO
3.3V
V
IO
GND
Vdd
USB2
Port
2
4
3
5
1
6
8
SMT1 JTAG Port Connections
Software Support
In addition to working seamlessly with all Xilinx tools, the SMT1 is supported by Digilent's Adept software and the
Adept SDK (the SDK can be freely downloaded from Digilent’s website). Adept includes a full-featured
programming environment, and a set of public APIs that allow user applications to directly drive the JTAG chain.
Using the SDK, custom applications can be created to drive JTAG ports on virtually any device. The SDK also
supports SPI ports, allowing applications to drive any SPI device using SPI Mode 0 or Mode 2. Please see the Adept
SDK reference manual for more information.
Mechanical Information
2 3 4 1
6 5 7 8
3.5mm
2.5mm
5mm 4mm
20mm
P
C
B
E
d
g
e
Recommended PCB pad geometry
15mm
23mm
2
1
.5
m
m
3mm 5mm
2
m
m
4mm
1
7
.5
m
m
SMT1 bottom-up view
