chipKIT Uno32 Reference Manual
www.digilentinc.com page 15 of 17
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
Connector
Pin #
chipKIT
Pin #
PIC32 Pin # PIC32 Signal Notes
J7-08 A09/23 24 TDO/PMA12/AN11/RB11
J7-09
A04/18
or 45 27 or 36 (TCK/PMA11/AN12/RB12) or (SDA1/RG3) selected by JP6
J7-10 A10/24 28 TDI/PMA10/AN13/RB13
J7-11
A05/19
or 46 29 or 37 (PMALH/PMA1/U2RTS/AN14/RB14) or (SCL1/RG2) selected by JP8
J7-12 A11/25 30 PMALL/PMA0/AN15/OCFB/CN12/RB15
