39 JH-04 51 RF13 U2RTS/BCLK2/RF13
90 JC-07 20 RG00 PMD8/RG0 also servo S5
89 JC-08 21 RG01 PMD9/RG1 also servo S6
57 N/A N/A RG02 D+/RG2 USB-3
56 N/A N/A RG03 D-/RG3 USB-2
10 JB-04 11 RG06 PMA5/SCK2/CN8/RG6
11 JB-03 10 RG07 PMA4/SDI2/CN9/RG7
12 JB-02 9 RG08 PMA3/SDO2/CN10/RG8
14 JB-01 8 RG09 PMA2/SS2/CN11/RG9
96 JC-01 16 RG12 TRD1/RG12 also servo S1
97 JC-02 17 RG13 TRD0/RG13 also servo S2
95 JC-03 18 RG14 TRD2/RG14 also servo S3
1 JC-04 19 RG15 RG15 also servo S4
