ChipKIT Pro MX4 Reference Manual
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 36 of 37
74
N/A
N/A
RC14
SOSCO/T1CK/CN0/RC14
Secondary Oscillator
64
N/A
N/A
RC15
OSC2/CLKO/RC15
Primary Oscillator
72
JH-08
53
RD00
SDO1/OC1/INT0/RD0
also J1-02
76
JD-02
25
RD01
OC2/RD1
77
JD-08
29
RD02
OC3/RD2
78
JE-08
37
RD03
OC4/RD3
81
JB-09
14
RD04
PMWR/OC5/CN13/RD4
82
JB-08
13
RD05
PMRD/CN14/RD5
83
JD-07
28
RD06
PMD14/CN15/RD6
also J1-10
84
JD-01
24
RD07
PMD15/CN16/RD7
68
JH-09
54
RD08
IC1/RTCC/RD8
also J1-08
69
JD-03
26
RD09
IC2/SS1/RD9
also J1-01
70
JD-09
30
RD10
IC3/SCK1/PMCS2/PMA15/RD10
also J1-04
71
JE-09
38
RD11
IC4/PMCS1/PMA14/RD11
79
JK-09
70
RD12
PMD12/IC5/RD12
80
JH-10
55
RD13
PMD13/CN19/RD13
also J1-09
47
JE-01
32
RD14
CN20/U1CTS/RD14
48
JE-04
35
RD15
U1RTS/BCLK1/CN21/RD15
93
JA-01
0
RE00
PMD0/RE0
94
JA-02
1
RE01
PMD1/RE1
98
JA-03
2
RE02
PMD2/RE2
99
JA-04
3
RE03
PMD3/RE3
100
JA-07
4
RE04
PMD4/RE4
3
JA-08
5
RE05
PMD5/RE5
4
JA-09
6
RE06
PMD6/RE6
5
JA-10
7
RE07
PMD7/RE7
18
JH-07
52
RE08
INT1/RE8
also J1-07
19
JE-07
36
RE09
INT2/RE9
also JP5,USB
OC_SENSE
87
JC-09
22
RF00
PMD11/RF0
also servo S7
88
JC-10
23
RF01
PMD10/RF1
also servo S8
52
JE-03
34
RF02
U1RX/RF2
51
N/A
N/A
RF03
USBID/RF3
USB-4
49
JH-03
50
RF04
PMA9/U2RX/CN17/RF4
50
JH-02
49
RF05
PMA8/U2TX/CN18/RF5
53
JE-02
33
RF08
U1TX/RF8
40
JH-01
48
RF12
U2CTS/RF12
