PowerPanel ® Business Edition
Copyright © 2006-2007 Cyber Power Systems, Inc. All rights reserved. 5
o
*Buck: The present input voltage of utility power is too high. The
Battery Backup will decrease output voltage to normal range.
o
Overload: The present load exceeds the maximum load the Battery
Backup can support.
o
Unknown: This is an abnormal status.
• Voltage: The present power voltage the Battery Backup is supplying to the
connected equipment.
• Frequency: The present power frequency the Battery Backup is supplying
to the connected equipment.
• Load: The power being supplied by Battery Backup, as a percentage of the
total load capacity. For some models, it may show information about the
loading watt.
• *Outlet number: Displays the present status of outlet number.
o
On: This outlet is on and will supply power.
o
Off: This outlet is off and will not supply power.
o
On Pending: This outlet is on pending an action such as a scheduled
event.
o
Off Pending: This outlet is off pending an action such as a scheduled
event.
Battery
• Status: Displays the present status of the battery packs.
o
Fully Charged: There is 100% battery capacity remaining.
o
Discharging: The Battery Backup is supplying battery power because
of a utility power failure, battery test, or utility power abnormality.
o
Charging: The batteries are being charged.
o
*Warning: The display shows warning state when the batteries
capacity is lower than 80%.
o
Capacity Critical Low: The capacity of the batteries is very low and
the Battery Backup may shutdown immediately.
o
*Battery Replacement Needed: The lifetime of batteries has expired.
You should replace the batteries as soon as possible.
o
*Not Present: There are no batteries detected.
o
Testing: The Battery Backup is performing a diagnostic test. You may
go to the Battery Backup Diagnostics page to see the results.
o
Unknown: This is an abnormal status.
• Voltage: The present voltage supplied by the batteries.
• Remaining Runtime: The amount of time that the Battery Backup can
supply power to the load.
• *Remaining Charge Time: The remaining time the battery packs required
to be fully charged.
• Capacity: The present capacity of the Battery Backup batteries, as a
percentage of full charge.
• *External Batteries: The number of external battery cabinets.
System
