PowerPanel ® Business Edition
Copyright © 2006-2007 Cyber Power Systems, Inc. All rights reserved. 4
MONITOR THE BATTERY BACKUP STATUS AND VIEW THE
BATTERY BACKUP INFORMATION
[AGENT ONLY]
• Battery Backup status monitoring
• View Battery Backup information
Battery Backup status monitoring
The Battery Backup Status page displays the Battery Backup status. The
Status page is the default logon page of PowerPanel Business Edition Agent.
The Battery Backup Status page displays four types of data about the Battery
Backup as follows:
• Utility, see Input.
• Battery Backup output, see Output.
• Battery status, see Battery
• Battery Backup status, see System
Input
• Status: Displays the present status of utility power supplied to the Battery
Backup.
o
Normal: Utility voltage and frequency is in normal range.
o
Blackout: There is no utility power.
o
Over Voltage: Utility voltage is above normal range. The Battery
Backup will switch to battery supplied power.
o
Under Voltage: Utility is below normal range. Battery Backup will
switch to battery supplied power.
o
*Frequency Failure: Frequency of utility power is out of range.
o
Unknown: This is an abnormal status.
• Voltage: The present voltage of utility supplied power.
• Frequency: The present frequency of utility supplied power.
Output
• Status: Displays the present status of the output power supplied to the
connected equipment.
o
Normal: The Battery Backup output is in normal range.
o
*Bypass: The Battery Backup is in bypass mode and continues
supplying utility power to the connected equipment.
o
*No Output: There is no output from the Battery Backup.
o
*Short Circuit: The Battery Backup will stop its output or shutdown
immediately due to a short circuit.
o
Boost: The present input voltage of utility power is too low. The
Battery Backup will increase output voltage to normal range.
