NetWare Connect Installation and Configuration
17
Novell NetWare
The Port Configuration screen is displayed:
7.
If necessary, use the cursor keys to scroll down the screen until the
VS1000 ports are displayed.
The default VS1000/VS1100 port names follow this form:
AIO_131{node}{port}
8.
Select the port to be configured and press Enter.
The cursor moves to the lower window and you can edit the Port
Name, Port Description, Modem Type, or Additional Parameters.
Table 4. Port Name Parameters
Parameter
Description
AIO
Indicates that this is an asynchronous I/O port.
131
The Novell hardware type, which for
InterChangeVS 1000 is always 131.
{node}
The node number, if specified in the load
statement. Otherwise, this is the device count (0
through 7), which is incremented each time the
load aiovs1 statement is executed.
That is, if you have two load aiovs1 statements
for two VS1000s, the ports on the unit initialized
by the first statement appear as AIO_1310{port}
and the ports on the unit initialized by the second
statement are AIO_1311{port}.
{port}
The port number. Ports are numbered from 000 to
015 (or 31, 47, or 63, depending on the number of
VS1100 expansion units installed).
