Interior Fuses
The interior fuse panel is located in the passenger com-
partment on the left side dash panel under the instru-
ment panel.
Cavity
Blade Fuse
Description
F13
15 Amp Blue
Low Beam Left
F32
10 Amp Red
Interior Lighting
F36
10 Amp Red
Intrusion Module / Siren
F37
7.5 Amp Brown
Aux. Switch Bank Module (ASBM)
F38
20 Amp Yellow
All Doors Lock/Unlock
F43
20 Amp Yellow
Washer Pump Front
F48
20 Amp Yellow
Horns
F49
7.5 Amp Brown
Lumbar Support
F51
10 Amp Red
Driver Window Switch / Power Mirrors – If
Equipped
7
MAINTAINING YOUR VEHICLE 631
